| Category |
Signal Beacon |
|
| Current |
Without Buzzer: |
|
|
24-230V AC/DC |
463mA ±10% |
|
– |
– |
|
With Buzzer: |
|
|
24-90V/DC |
455mA ±10% |
|
24-60V/AC |
542mA ±10% 50-60 Hz |
| Body material |
ABS (Body) + Polycarbonate (Lens) |
|
| Lens colors |
Red, Green, Yellow, Blue, White |
|
| Lens diameter |
Ø 90/Ø 100/Ø 125mm |
|
| Light source |
POWER LED |
|
| Light mode |
Strobe |
|
| Input response time |
on/off: 10ms max. |
|
| Tone |
1 tone (button control) |
|
| Alarm |
117 dB at 1m (3.3ft) |
|
| Connection |
Wire |
|
| Mounting type |
Surface, Wall |
|
| Operation conditions |
-20°C to +50°C (-4°F to +122°F) |
|
| Expected life |
Min. 50,000 hrs |
|
| Degree of protection |
IP65 |
|
| Protection |
Water, Dust, Heat, and UV Ray Resistant |
|
| Certificates & Quality Doc. |
ISO-9001, CE, RoSH2 and EAC |
