| Category |
Obstruction Light |
|
| Light Intensity |
Low intensity – B-type – 32cd |
|
| Current |
SNT-U125-DT2 series: |
|
| SNT-U125-DT2-12 |
12V/DC |
|
| SNT-U125-DT2-24 |
24V/DC |
|
| SNT-U125-DT2-48 |
48V/DC |
|
| SNT-U125-DT2-22 |
85-260V AC/DC |
|
| Body material |
ABS (lens body) + Metal casting (body) + Polycarbonate (Lens) |
|
| Lens colors |
Red, Yellow, Green, Blue, White |
|
| Lens diameter |
ø125mm |
|
| Light source |
SMD LED |
|
| Light mode |
Flashing, Continuous, Strobe |
|
| Input response time |
on/off: 10ms max. |
|
| Tone |
– |
|
| Alarm |
– |
|
| Connection |
Wire |
|
| Mounting type |
Surface |
|
| Operation conditions |
-20°C to +50°C (-4°F to +122°F) |
|
| Expected life |
Min. 50,000 hrs |
|
| Degree of protection |
IP65 |
|
| Protection |
Water, Dust, Heat, and UV Ray Resistant |
|
| Certificates & Quality Doc. |
ISO-9001, CE, RoSH2 and EAC |
