| Category |
Warning Horn |
|
| Current |
SNT-B7013 series: |
|
|
12-24V AC/DC |
|
|
– |
|
|
SNT-B7022 series: |
|
|
40-250V AC/DC |
|
|
– |
|
| Body material |
ABS (Body) + Polycarbonate (Lens) |
|
| Lens colors |
Red, Yellow, Green, Blue, White |
|
| Lens diameter |
ø70mm |
|
| Light source |
SMD LED |
|
| Light mode |
Steady-Flashing, Strobe, Rotary |
|
| Input response time |
on/off: 10ms max. |
|
| Tone |
2 tone |
|
| Alarm |
120 dB at 1m (3.3ft) |
|
| Connection |
Wire |
|
| Mounting type |
Wall |
|
| Operation conditions |
-20°C to +50°C (-4°F to +122°F) |
|
| Expected life |
Min. 50,000 hrs |
|
| Degree of protection |
IP65 |
|
| Protection |
Water, Dust, Heat, and UV Ray Resistant |
|
| Certificates & Quality Doc. |
ISO-9001, CE, RoSH2 and EAC |
