| Operating principle |
Inductive |
| Evaluation |
digital |
| Size |
M8 x 1 (thread) |
| Design |
screw |
| Mounting |
flush |
| Characteristics |
increased operating distance |
| Operating distance |
2 mm |
| Standardized measuring plate |
8 x 8 x 1 mm |
| Service voltage |
10 … 30 V DC |
| Internal power consumption |
< 10 mA |
| Switching output |
npn, 200 mA, NO |
| Switching hysteresis |
5 % |
| Voltage drop |
< 2,4 V |
| Switching frequency |
3.000 Hz |
| Ambient temperature |
-25 … +70 °C |
| Insulation voltage endurance |
500 V |
| Protection class |
IP 67 |
| Casing material |
stainless steel V2A (1.4301 / AISI 304) |
| Connection |
Connector, M8, 3-poled |
| Connecting cable |
TK … |
| Produktfamilie |
Sn + |
